Zettler Electronics AZ943-1AH-12DEFGW PCB Relay 12V DC Miniature 1pc

Zettler Electronics
Order Code:

08-3690

Brand: Zettler Electronics MPN: AZ943-1AH-12DEFGW EAN-13: 2050006598924
Qty Unit Price (Ex VAT)
5+ £1.04
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
190 available to back orderBack-order availability date - 19/04/2026

The Zettler Electronics AZ943-1AH-12DEFGW is a PCB relay featuring a 12 V DC coil voltage and a 15 A switching capacity. It is ideal for printed circuit board applications, offering reliable performance in compact designs. This mini relay is typically used in automotive, industrial controls, and consumer electronics.
Coil Voltage 12V DC
Contact Configuration 1NO
Switching Current 15A
Coil Resistance 400Ω
Contact Material AgSnO2
Control Mode monostable, 1 coil
Dimensions (L x W x H) 19.00 x 15.30 x 15.70 mm
Durability 1 x 10E6
Height 15.70mm
Length 19.00mm
Max. pick-up Voltage 26.8V DC
Max. switching capacity 300W
Max. temperature +85°C
Min. pick-up Voltage 9V DC
Minimum Temperature -40°C
Mounting Type PCB
Response Time 10ms
Switching Voltage Max 30V DC
Type PCB relay
Width 15.30mm
