Zettler Electronics AZ851-12 SMD Relay 12V DC 1PC 1-2 Change-Overs

Zettler Electronics
Standard range
Order Code:

08-3661

Brand: Zettler Electronics MPN: AZ851-12
Qty Unit Price (Ex VAT)
1+ £2.46
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
12 in stock, despatched in 4 working days

Zettler Electronics manufactures the AZ851-12 SMD relay, featuring two change-overs and rated for 12 V DC operations. This mini relay is suitable for surface-mounted devices and printed circuit boards. It is commonly used in electronic circuits requiring PCB mount relays.
Height 6.20mm
Length 14.20mm
Width 11.50mm
Coil nominal voltage 12V DC
Contact material AgPd + Au
Contact type 2 change-overs
Control mode monostable, 1 coil
Dim (L x W x H) 14.20 x 11.50 x 6.20 mm
Durability 1 x 10E8
Max. pick-up voltage 30V DC
Max. switching capacity 30W
Max. temperature +85°C
Min. pick-up voltage 9V DC
Min. temperature -40°C
Misc Attribute Zettler electronics
Resistance (coil) 1028Ω
Response time 2ms
RoHS-compliant Yes
Switching current (max.) 1
Switching voltage (max.) 220V DC
Type SMD relay
