Zettler Electronics AZ832P2-2C-12DE PCB Relay 12V DC 3A 2 CO 1pc

Zettler Electronics
Order Code:

08-3654

Brand: Zettler Electronics MPN: AZ832P2-2C-12DE EAN-13: 2050006578308
Qty Unit Price (Ex VAT)
2+ £2.13
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
152 in stock, despatched in 4 working days

The Zettler Electronics AZ832P2-2C-12DE is a PCB mount relay that operates at 12 V DC and can handle a current of 3 A. It features two change-over contacts, making it suitable for various switching applications. This mini relay is commonly used in electronics projects and circuit board designs requiring reliable switching functions.
Coil Voltage 12V DC
Contact Configuration 2CO (DPDT)
Switching Current 3A
Coil Resistance 720Ω
Connection Solder pins
Control Mode Bistable, 2 Coils
Dimensions (L x W x H) 20.2 x 10 x 10.65 mm
Durability 2 x 10E7
Fall Time 3ms
Height 10.65mm
Length 20.2mm
Max. switching capacity 60W
Max. temperature +85°C
Minimum Temperature -40°C
Mounting Type PCB
Response Time 3ms
Type PCB relay
Width 10mm
