Zettler Electronics AZ770-1C-24DEK PCB Relay 24V DC 5A 1 Change-Over 1 Piece

Zettler Electronics
Order Code:

08-3640

Brand: Zettler Electronics MPN: AZ770-1C-24DEK EAN-13: 2050006577806
Qty Unit Price (Ex VAT)
3+ £1.63
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
Available to back orderBack order, lead time 11 days

The AZ770-1C-24DEK is a PCB relay manufactured by Zettler Electronics, designed to operate at 24 V DC with a switching capacity of 5 A. It features a single change-over contact configuration and is suitable for applications requiring reliable switching in electronic and control circuits. This relay is ideal for use in systems where space is limited, providing effective control in printed circuit board designs.
Type PCB relay
Coil Voltage 24V DC
Switching Current 5A
Length 17.85mm
Width 10.35mm
Height 12.95mm
Connection Solder pins
Contact Material AgNi
Contact Type 1 change-over
Control Mode monostable, 1 coil
Dim (L x W x H) 17.85 x 10.35 x 12.95 mm
Durability 1 x 10E6
Fall Time 4ms
Max. switching capacity 90W
Max. temperature +85°C
Min. temperature -40°C
Resistance (coil) 1280Ω
Response Time 8ms
