Zettler Electronics AZ764-1CE-230A PCB Relay 230V AC Change-Over 16A

Zettler Electronics
Order Code:

08-3635

Brand: Zettler Electronics MPN: AZ764-1CE-230A EAN-13: 2050006599167
Qty Unit Price (Ex VAT)
1+ £6.67
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
2 available to back orderBack-order availability date - 09/01/2026

Zettler Electronics manufactures the AZ764-1CE-230A, a miniature PCB relay designed for 230 V AC applications. This relay features a single change-over contact and is suitable for printed circuit board mounting. It is typically used in automation systems and electronic devices requiring reliable switching.
Type PCB relay
Coil Voltage 230V AC
Switching Current 16
Length 29.00mm
Width 12.70mm
Height 15.70mm
Contact Material AgSnO2
Contact Type 1 change-over
Control Mode monostable, 1 coil
Dim (L x W x H) 29.00 x 12.70 x 15.70 mm
Durability 3 x 10E7
Max. pick-up voltage 345V AC
Max. switching capacity 480W
Max. temperature +70°C
Min. pick-up voltage 172.5V AC
Min. temperature -40°C
Resistance (coil) 38500Ω
Response Time 7ms
Switching voltage (max.) 300V DC
