Zettler Electronics AZ733-2CE-9DE PCB Relay 9V DC 12A 2 Change-Overs 1pc

Zettler Electronics
Order Code:

08-3600

Brand: Zettler Electronics MPN: AZ733-2CE-9DE EAN-13: 4064161192291
Qty Unit Price (Ex VAT)
1+ £4.04
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
280 in stock, despatched in 4 working days

The Zettler Electronics AZ733-2CE-9DE PCB relay operates at 9 V DC and can handle currents up to 12 A. It features two change-over contacts, suitable for switching applications. Typical uses include electronic control systems and automation applications.
Coil Voltage 9V DC
Contact Configuration 2CO (DPDT)
Switching Current 12A
Coil Resistance 160Ω
Connection Solder pins
Contact Material AgSnO
Control Mode monostable, 1 coil
Dimensions (L x W x H) 29 x 13 x 25.9 mm
Height 25.9mm
Insulation Voltage 1000V
Length 29mm
Max. pick-up Voltage 17.4V DC
Max. temperature +85°C
Min. pick-up Voltage 6.3V DC
Minimum Temperature -40°C
Mounting Type PCB
Type PCB relay
Width 13mm
