WP 257-002-1-50-00-6 SIL Socket Precision 1x2 Pins Round/Square 0.4-0.56mm

Image Representative of Range

WP 257-002-1-50-00-6 SIL Socket Precision 1x2 Pins Round/Square 0.4-0.56mm

W & P Products
Standard range
Order Code:

10-9581

Brand: W & P Products MPN: 257-002-1-50-00-6 EAN-13: 2050001574503
Qty Unit Price (Ex VAT)
1+ £0.259
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
730 in stock, despatched in 4 working days

W & P Products manufactures the precision SIL socket with a single row of 2 pins. It is part number 257-002-1-50-00-6 and is typically used in electronic receptacles. This product is ideal for secure and precise connections in electronic assemblies.
Case material Thermoplastic material
Connection Print
Connector orientation Perpendicular (to the PCB)
Connector type Power strip, straight
Contact material Copper alloy
Contact surface Tin plated
CS 2mm
Dim (L x W x H) 7.40 x 4.00 x 2.20 mm
Dimensions L x B x H 4 x 2.2 x 7.4 mm
Factory colour Black
Height 2.20mm
Industrial packaging No
Length 7.40mm
Manufacturer part # 257-002-1-50-00-6
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute 257-002-1-50-00-6
No. of rows 1
Nominal current 3A
Nominal current - rounded value 3A
Nominal voltage 150V DC
Pin length (PCB) 3.20mm
Pin Ø 0.40mm
Pin shape Circular
Pins per row 2
RoHS-compliant Yes
Separable No
Socket depth 3.50mm
Total number of pins 2
Type Receptacles (precision)
Width 4.00mm
