Weipu SP2113 S7 SP21 Bullet Connector 7-Pin UV/Water Resistant Socket

Weipu manufactures the SP2113 / S 7 bullet connector socket, which is built-in and features a total of 7 pins. This round connector, part of the SP21 series, is known for its reliability and robustness. It is typically used in industrial and outdoor applications due to its durable design.

Type	Socket, built-in
Number of Contacts	7
Connector Size	29 mm dia
Gender	Socket
Case Material	PPS
Connection	Soldering
Connection Angle	180°
Contact Material	Gold plated
Cross-section range	2 mm² (max)
Current Rating	10A
IP Rating	IP68
max. cross section	2mm²
Mounting Hole Diameter	21mm
Nominal Voltage	250V
Series	SP21
Termination	Screw-type locking
Wire Gauge (AWG)	14
