Weipu SP2113/P12 SP21 Bullet Connector Plug 12-Pin UV & Water Resistant

Image Representative of Range

Weipu SP2113/P12 SP21 Bullet Connector Plug 12-Pin UV & Water Resistant

Weipu
Standard range
Order Code:

13-5361

Brand: Weipu MPN: SP2113 / P12 EAN-13: 2050001515254
Qty Unit Price (Ex VAT)
1+ £5.09
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
79 in stock, despatched in 4 working days

The Weipu SP2113/P12 bullet connector is a robust plug mount featuring 12 pins, ideal for secure electrical connections. Manufactured by Weipu, it is part of the SP21 series of round connectors, known for their durability and reliability. This connector is typically used in industrial and outdoor applications requiring water and dust resistance.
Type Bullet connector
AWG 18
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Plug, mount
Contact material Gold plated
Cross-section range 0.758 mm² (max)
IP rating IP68
max. cross section 0.758mm²
Max. temperature +125°C
Min. temperature -40°C
Misc Attribute Weipu Connector
Mounting hole diameter 21mm
Nominal current 10A
Nominal current - rounded value 10A
Nominal voltage 250V
Number of pins 12
RoHS-compliant Yes
Seal Screw-type locking
Series SP21
Total no. of pins 12
