Weipu SP2112/S3 SP21 Connector Socket 3 Pins Screw Lock Waterproof

Image Representative of Range

Weipu SP2112/S3 SP21 Connector Socket 3 Pins Screw Lock Waterproof

Weipu
Standard range
Order Code:

13-5346

Brand: Weipu MPN: SP2112 / S 3 EAN-13: 2050001515094
Qty Unit Price (Ex VAT)
1+ £4.25
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
54 in stock, despatched in 4 working days

The Weipu SP2112/S 3 bullet connector is a built-in socket with three pins, part of the SP21 series of round connectors. Manufactured by Weipu, it is known for its durability and reliability in various environmental conditions. This connector is ideal for industrial equipment and outdoor applications where robust and secure connections are required.
Type Bullet connector
AWG 11
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Socket, built-in
Contact material Gold plated
Cross-section range 4.17 mm² (max)
IP rating IP68
max. cross section 4.17mm²
Misc Attribute Weipu Connector
Mounting hole diameter 21mm
Nominal current 16A
Nominal current - rounded value 16A
Nominal voltage 400V
Number of pins 3
RoHS-compliant Yes
Seal Screw-type locking
Series SP21
Total no. of pins 3
