Weipu SP2112/S12 SP21 Socket Connector Built-In 12 Pins UV Resistant

Image Representative of Range

Weipu SP2112/S12 SP21 Socket Connector Built-In 12 Pins UV Resistant

Weipu
Standard range
Order Code:

13-5344

Brand: Weipu MPN: SP2112 / S 12 EAN-13: 2050001515162
Qty Unit Price (Ex VAT)
1+ £5.09
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
37 in stock, despatched in 4 working days

The Weipu SP2112 bullet connector socket is a built-in round connector with 12 pins. Manufactured by Weipu, this connector is part of the SP21 series, known for its durability and reliable connections. Typically used in industrial and outdoor applications, it ensures secure data or power transmission in harsh environments.
Type Bullet connector
AWG 18
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Socket, built-in
Contact material Gold plated
Cross-section range 0.758 mm² (max)
IP rating IP68
max. cross section 0.758mm²
Misc Attribute Weipu Connector
Mounting hole diameter 21mm
Nominal current 12A
Nominal current - rounded value 12A
Nominal voltage 250V
Number of pins 12
RoHS-compliant Yes
Seal Screw-type locking
Series SP21
Total no. of pins 12
