Weipu SP2110/P 9 II SP21 Bullet Connector Plug 9 Pins Water-Resistant

The Weipu SP2110/P 9 II is a bullet connector plug with a straight design and nine total pins, part of the SP21 series of round connectors. Manufactured by Weipu, this connector is known for its durability and reliable electrical connections, making it ideal for industrial and outdoor applications. The connector is typically used in situations requiring secure and waterproof connections between devices.

Type	Plug, straight
Number of Contacts	9
Connector Size	29 mm dia
Gender	Plug
Cable Ø (max.)	12mm
Cable Ø range	7 - 12mm
Cable Ø up to	7mm
Case Material	PPS
Connection	Soldering
Connection Angle	180°
Contact Material	Gold plated
Cross-section range	0.758 mm² (max)
Current Rating	5A
IP Rating	IP68
max. cross section	0.758mm²
Max. temperature	+105°C
Min. temperature	-55°C
Nominal Voltage	250V
Series	SP21
Termination	Screw-type locking
Wire Gauge (AWG)	18
