Weipu SP1312/S SP13 Bullet Connector Socket 3-Pin Built-In UV Resistant

Image Representative of Range

Weipu SP1312/S SP13 Bullet Connector Socket 3-Pin Built-In UV Resistant

Weipu
Standard range
Order Code:

13-5291

Brand: Weipu MPN: SP1312 / S 3 EAN-13: 2050001514547
Qty Unit Price (Ex VAT)
2+ £2.94
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
63 in stock, despatched in 4 working days

The Weipu SP1312/S 3 is a bullet connector socket featuring a built-in design with three pins, part of the SP13 series. Manufactured by Weipu, this connector is ideal for robust and reliable electrical connections in outdoor and industrial environments. Its sturdy construction makes it suitable for applications requiring a durable, waterproof connection.
Type Bullet connector
AWG 14
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Socket, built-in
Contact material Gold plated
Cross-section range 2 mm² (max)
Factory colour Black
IP rating IP68
max. cross section 2mm²
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute Weipu Connector
Mounting hole diameter 13mm
Nominal current 13A
Nominal current - rounded value 13A
Nominal voltage 600V
Number of pins 3
RoHS-compliant Yes
Seal Screw-type locking
Series SP13
Total no. of pins 3
