Weipu SP1312/P2 SP13 Bullet Connector 2 Pins UV & Water Resistant

Image Representative of Range

Weipu SP1312/P2 SP13 Bullet Connector 2 Pins UV & Water Resistant

Extended range
Order Code:

13-5283

Brand: Weipu MPN: SP1312 / P 2 EAN-13: 2050001514462
Qty Unit Price (Ex VAT)
2+ £2.94
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
Available to back orderBack order, lead time 11 days

The Weipu SP1312/P 2 is a round bullet connector plug with a total of 2 pins from the SP13 series. It is distinguished by its durable build and suitability for mounting applications. Typically used in industrial and outdoor settings, this connector ensures reliable electrical connections.
Type Bullet connector
AWG 14
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Plug, mount
Contact material Gold plated
Cross-section range 2 mm² (max)
Factory colour Black
IP rating IP68
max. cross section 2mm²
Max. temperature +130°C
Min. temperature -40°C
Misc Attribute Weipu Connector
Mounting hole diameter 13mm
Nominal current 25A
Nominal current - rounded value 25A
Nominal voltage 230V
Number of pins 2
RoHS-compliant Yes
Seal Screw-type locking
Series SP13
Total no. of pins 2
