Weipu SP1311/P2I SP13 Bullet Connector 2 Pins Screw Lock Waterproof

Image Representative of Range

Weipu SP1311/P2I SP13 Bullet Connector 2 Pins Screw Lock Waterproof

Weipu
Standard range
Order Code:

13-5267

Brand: Weipu MPN: SP1311 / P 2 I EAN-13: 2050001514301
Qty Unit Price (Ex VAT)
2+ £3.34
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
9 in stock, despatched in 4 working days

The SP1311 / P 2 I bullet connector by Weipu is a straight plug with 2 pins, belonging to the SP13 series of round connectors. This connector offers secure and reliable connections and is typically used in industrial, automotive, and outdoor applications. Its robust design ensures durability in various environmental conditions.
Type Bullet connector
AWG 14
Cable Ø (max.) 6.5mm
Cable Ø range 4 - 6.5 mm
Cable Ø up to 4mm
Case material PPS
Connection Soldering
Connection angle 180°
Connector type Plug, straight
Contact material Gold plated
Cross-section range 2 mm² (max)
IP rating IP68
max. cross section 2mm²
Max. temperature +100°C
Min. temperature -30°C
Misc Attribute Weipu Connector
Nominal current 20A
Nominal current - rounded value 20A
Nominal voltage 250V
Number of pins 2
RoHS-compliant Yes
Seal Screw-type locking
Series SP13
Total no. of pins 2
