Weipu SP1310/S 5 II SP13 Bullet Connector 5 Pins Straight Waterproof

The Weipu SP1310/S 5 II bullet connector is a straight socket with 5 pins, part of the SP13 series of round connectors. It is known for its reliable electrical connections and durability, making it suitable for use in various industrial and automotive applications. Manufactured by Weipu, this connector is designed for situations requiring secure and stable electrical connections.

Type	Socket, straight
Number of Contacts	5
Connector Size	20 mm dia
Gender	Socket
Cable Ø (max.)	8mm
Cable Ø range	5 - 8mm
Cable Ø up to	5mm
Case Material	PPS
Connection	Soldering
Connection Angle	180°
Contact Material	Gold plated
Cross-section range	0.785 mm² (max)
Current Rating	20A
IP Rating	IP68
max. cross section	0.785mm²
Max. temperature	+100°C
Min. temperature	-40°C
Nominal Voltage	250V
Series	SP13
Termination	Screw-type locking
Wire Gauge (AWG)	18
