Weipu SF1210/S2 SF12 Bullet Connector Socket 2 Pins Compact Secure

Image Representative of Range

Weipu SF1210/S2 SF12 Bullet Connector Socket 2 Pins Compact Secure

Weipu
Standard range
Order Code:

13-5203

Brand: Weipu MPN: SF1210/S2 I EAN-13: 2050001554895
Qty Unit Price (Ex VAT)
1+ £8.40
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
19 in stock, despatched in 4 working days

Weipu manufactures the SF1210/S2 I bullet connector, a straight socket with two pins from the SF12 series. This connector is known for its robust design and reliable connectivity, suitable for industrial and outdoor applications. It is commonly used in electronic installations where secure and efficient connection is essential.
Type Bullet connector
AWG 14
Cable Ø (max.) 6.5mm
Cable Ø range 4 - 6.5 mm
Cable Ø up to 4mm
Case material Brass, chrome plated
Connection Soldering
Connection angle 180°
Connector type Socket, straight
Contact material Brass gold plated
Cross-section range 2 mm² (max)
IP rating IP67
max. cross section 2mm²
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute Weipu Connector
Nominal current 3A
Nominal current - rounded value 3A
Nominal voltage 125V
Number of pins 2
RoHS-compliant Yes
Seal Push-Pull
Series SF12
Total no. of pins 2
