Weipu SF1210/P2 SF12 Bullet Connector Plug 2 Pins Push-Pull Locking

Image Representative of Range

Weipu SF1210/P2 SF12 Bullet Connector Plug 2 Pins Push-Pull Locking

Weipu
Standard range
Order Code:

13-5196

Brand: Weipu MPN: SF1210/P2 I EAN-13: 2050001554826
Qty Unit Price (Ex VAT)
1+ £8.40
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
65 in stock, despatched in 4 working days

The Weipu SF1210/P2 I bullet connector is a straight plug designed with two pins, part of the SF12 series of round connectors. Manufactured by Weipu, it is suitable for applications requiring secure and reliable electrical connections. Typically used in industrial equipment, its robust design ensures durability in challenging environments.
Type Bullet connector
AWG 14
Cable Ø (max.) 6.5mm
Cable Ø range 4 - 6.5 mm
Cable Ø up to 4mm
Case material Brass, chrome plated
Connection Soldering
Connection angle 180°
Connector type Plug, straight
Contact material Brass gold plated
Cross-section range 2 mm² (max)
IP rating IP67
max. cross section 2mm²
Max. temperature +95°C
Min. temperature -30°C
Misc Attribute Weipu Connector
Nominal current 7A
Nominal current - rounded value 7A
Nominal voltage 250V
Number of pins 2
RoHS-compliant Yes
Seal Push-Pull
Series SF12
Total no. of pins 2
