Weidmüller manufactures the 9021020000 ferrule, which is 0.25 mm², partially insulated, and yellow. This product comes in a packaging unit of 500 pieces, typically used for electrical wire terminations to improve connectivity and safety. It is ideal in industrial applications requiring precise and reliable electrical connections.
| Insulation |
Partially insulated |
| Colour |
Yellow |
| Pin Length |
12mm |
| Maximum Wire Size mm2 |
0.25mm² |
| Number of Entries |
1 |
| Approvals |
UR |
| AWG size |
24 |
| Certificate no. (cULus) |
E499744 |
| Collar diameter (D2) |
1.8mm |
| Color |
Yellow |
| Colour code |
Telemecanique |
| Conductor Cross-section |
0.25mm² |
| Construction type |
Standard |
| Contact Material |
Cathode copper, tin plated |
| Contact surface diameter (D1) |
0.8mm |
| Contact surface length (L2) |
8mm |
| Contains Lead |
No |
| Cross-section range |
0.25 mm² x 8 mm |
| Description of article |
Wire end ferrule with |
| ECLASS 14 |
27-40-02-01 |
| ECLASS 15.0 |
27-40-02-01 |
| ETIM 10 |
EC000005 |
| ETIM 8.0 |
EC000005 |
| ETIM 9.0 |
EC000005 |
| For cables resistant to short circuit |
false |
| GTIN (EAN) |
4008190184230 |
| Height |
90mm |
| Industrial packaging |
Yes |
| Insulated |
true |
| Insulation Material |
PP |
| L1 in mm |
12.00mm |
| Length |
12mm |
| Material |
Copper |
| Material insulation |
Polypropylene (PP) |
| Maximum Wire Size AWG |
24 |
| Metal sleeve thickness (S1) |
0.15mm |
| Misc Attribute |
H0,25/12T GE |
| Net weight |
0.05g |
| Nominal cross section |
0.25 |
| Package Quantity |
1 |
| Packaging |
Bag |
| Plastic collar thickness (S2) |
0.25mm |
| Qty. |
500 items |
| Radiation Hardening |
No |
| REACH SVHC |
No SVHC above 0.1 wt% |
| Reel/roll packaging |
false |
| ROHS |
Conform |
| RoHS Compliance Status |
Compliant without exemption |
| RoHS Compliant |
Yes |
| Sleeve length |
8mm |
| Stripping length |
10mm |
| Surface protection |
Tinned |
| Type |
Ferrule |
| UL File Number Search |
UL Website |
| Weight |
0.052g |
| Width |
30mm |
| Wire connection cross section AWG, |
AWG 24 |
| Wire/Cable Gauge |
24AWG |
