Weidmüller offers the 2706200050 cable, a 1-metre long, high-quality, flexible, black cable. This cable features robust construction suitable for various electrical connections and is ideal for use in industrial environments. Its flexibility and durability make it a reliable choice for engineers seeking dependable performance in challenging conditions.
| Colour |
Black |
| Length |
5 |
| Type |
Cable |
| Abrasion resistance |
very good |
| Acceleration |
4 m/s² |
| Anti-kink sleeve |
None |
| Arrangement of wire cores |
Star-quad |
| Bending cycles |
3 Mio |
| Cable construction |
1x4 |
| Cable Type |
SF/UTP |
| Capacity at 1 kHz |
52 nF/km |
| Category |
5 |
| Characteristic impedance |
100 ± 15 O at 1–100 |
| Colour anti-kink sleeve |
Black |
| Colour outer sheath |
Green |
| Colour sequence or wires - wire pairs |
white, yellow, blue, orange |
| Complete shielding |
Aluminium foil, Shielding |
| Connector standard |
IEC 61076-2-114 |
| Cross-section |
4*AWG 22/7 - 0.32mm² |
| Delay skew |
40 ns/100m |
| Diameter of inner sheathing |
3.9mm |
| ECLASS 14 |
27-06-03-08 |
| ECLASS 15.0 |
27-06-03-08 |
| ETIM 10 |
EC002599 |
| ETIM 8.0 |
EC002599 |
| ETIM 9.0 |
EC002599 |
| Filler |
As central element |
| Fire propagation |
No |
| Flame retardant |
According to IEC/EN 60332-3-24 |
| GTIN (EAN) |
4050118742930 |
| Halogen |
halogen-free, according to |
| Halogen free according to EN IEC 60754-1 |
false |
| Halogen free according to EN IEC 60754-2 |
true |
| Halogen free according to EN IEC 60754-3 |
false |
| Installation temperature |
-20 °C...60°C |
| Insulation |
PE |
| Insulation cross-section |
1.5mm |
| Length (inches) |
196.8504 inch |
| Loop resistance |
120 O/km |
| Material connector housing, connection 1 |
Plastic |
| Material connector housing, connection 2 |
Plastic |
| Material sheath |
PUR |
| Min. bending radius, once only |
5 x cable diameter |
| Min. bending radius, repetitive |
7.5 x cable diameter |
| Net weight |
318.5g |
| Number of wires |
4 |
| NVP value |
66 |
| Oil resistant according to EN IEC 60811-404 |
true |
| Operating Temperature |
-40 °C...70°C |
| Operating voltage (UL rating) |
600 V |
| Operating voltage, UL |
600 V |
| Overlap of shielding braid |
85 % |
| Pin assignment |
Other |
| Plug left |
M8, D-coded, IP67, male |
| Plug right |
M8, D-coded, IP67, male |
| Pulling force |
= 150 N |
| Qty. |
1 items |
| REACH SVHC |
Lead 7439-92-1 |
| Resistance differential |
3 % |
| Resistance to oils |
in accordance with IEC |
| Resistance to spread of flame |
in accordance with IEC |
| ROHS |
Conform |
| RoHS Compliance Status |
Compliant with exemption |
| SCIP |
67cf1078-beca-4687-860b-dc475a6ec24a |
| Sheath diameter, max. |
6.7mm |
| Sheath diameter, min. |
6.3mm |
| Sheathing colour |
green (RAL 6018) |
| Sheathing material thickness |
0.9mm |
| Shielding |
SF/UTP |
| Shielding braid thickness |
0.13mm |
| Signal propagation time |
5.3 ns/m |
| Silicone-free |
Yes |
| Speed |
180 m/min |
| Standard designations |
2YH(ST)C11Y |
| Standard, insulating material |
DIN EN 50290-2-23 (VDE |
| Standard, shielding material |
DIN EN 13602 Cu-ETP- |
| Standard, wire material |
DIN EN 13602 Cu-ETP-A |
| Storage temperature |
-50 °C...70°C |
| Strands |
7 |
| Test voltage: wire-wire-shield |
2000 Veff, 50 Hz, 1 min |
| Transfer impedance |
20 mO/m at 10 MHz |
| Type of connector connection 1 |
Other |
| Type of connector connection 2 |
Other |
| UV-resistant |
Yes |
| Version |
Dragline cable, PROFINET, M8 D-code - IP67 |
| Wire core insulation thickness |
0.38mm |
| Wire material |
Stranded tin-plated copper |
