Weidműller 1803070000 Terminal Block Female Unshrouded 5POS 5.08mm Screw RA

Weidmüllers 1803070000 is a female terminal block featuring an unshrouded design with five positions and 5.08mm pitch, incorporating a screw connection that is right-angled. This product is primarily used in electrical connections where reliable and secure wire termination is required. Typical applications include use in industrial control panels and connection systems within automation equipment.

Pitch	5.08mm
No. of Rows	1
Current Rating	19A
Colour	black
(Tu=20°C)	(Tu=40°C)
(Tu=40°C)	pollution degree II/2
57 106	0470
Alternative product	BLZP 5.08HC/05/180F SN BK BX
Available until	2023-07-30T00:00:00+02:00
Can be coded	Yes
Certificate No. (CSA)	200039-1121690
Certificate No. (UR)	E60693
Clampable conductor	Cross-section for conductor connection
Clamping range, max.	3.31mm²
Clamping range, min.	0.13mm²
Clamping screw	M 2.5
class/ pollution degree II/2	class/ pollution degree III/2
Colour chart (similar)	RAL 9011
Comparative Tracking Index (CTI)	= 200
Conductor outlet direction	180°
Contact Material	Copper Alloy
Contact Plating	Tin
Contact surface	tinned
Cross-section for conductor connection	Type
Delivery status	Discontinued
Depth	20.1mm
Depth (inches)	0.7913 inch
ECLASS 14	27-46-02-02
ECLASS 15.0	27-46-02-02
ETIM 10	EC002638
ETIM 8.0	EC002638
ETIM 9.0	EC002638
Flexible, max. H05(07) V-K	2.5mm²
Flexible, min. H05(07) V-K	0.2mm²
Gender	Female
GTIN (EAN)	4032248258178
Height	15.2mm
Height (inches)	0.5984 inch
Housing Colour	Black
Institute (CSA)	CSA
Institute (UR)	UR
Insulating material	PBT
Insulating material group	IIIa
IPC conformity	Conformity: The products are developed, manufactured and delivered according international
L1 in inches	0.800 "
L1 in mm	20.32mm
Layer structure of plug contact	4...8 µm Sn hot-dip tinned
Max Current Rating	10A
Max Operating Temperature	100°C
Min Operating Temperature	-55°C
Mount	Panel
Net weight	9.86g
Notes	•Additional variants on request
Number of Circuits	5
Number of Contacts	5
Number of Poles	5
Number of Positions	5
Number of Rows	1
Operating temperature, max.	100°C
Operating temperature, min.	-50°C
Orientation	Right Angle
Packaging	Bulk
Pin series quantity	1
Pitch in inches (P)	0.200 "
Pitch in mm (P)	5.08mm
Plug gauge in accordance with EN	2.8 mm x 2.0 mm; 2.4 mm
Plugging cycles	25
Plugging force/pole, max.	8.5 N
pollution degree III/2	pollution degree III/3
Product data	IEC: 400 V / 19 A / 0.2 - 2.5mm²
Product family	OMNIMATE Signal - series
Protection degree	IP20
Pulling force/pole, max.	6.5 N
Radiation Hardening	No
Rated cross-section	2.5mm²
Rated current (Use group B / CSA)	15 A
Rated current (Use group B / UL 1059) 15 A	Rated current (Use group D / UL 1059) 10 A
Rated current (Use group D / CSA)	10 A
Rated voltage (Use group B / CSA)	300 V
Rated voltage (Use group B / UL 1059) 300 V	Rated voltage (Use group D / UL 1059) 300 V
Rated voltage (Use group D / CSA)	300 V
REACH SVHC	No SVHC above 0.1 wt%
Reach SVHC Compliant	Unknown
Reference text	The outside diameter of the plastic collar should not be larger than the pitch (P), Length of ferrules
Reference to approval values	Specifications are
ROHS	Conform
RoHS Compliance Status	Compliant without exemption
RoHS Compliant	Yes
Screwdriver blade	0.6 x 3.5
Screwdriver blade standard	DIN 5264
Series	BLZ
Solid, max. H05(07) V-U	2.5mm²
Solid, min. H05(07) V-U	0.2mm²
Storage temperature, max.	70°C
Storage temperature, min.	-40°C
Stripping length	7mm
Temperature range, installation, max.	100°C
Temperature range, installation, min.	-25°C
Termination	Screw
tested acc. to standard	IEC 60664-1, IEC 61984
Type of connection	Field connection
UL 94 flammability rating	V-0
UL File Number Search	UL Website
Version	PCB plug-in connector, female plug, 5.08 mm,
Voltage Rating	400V
Volume resistance	=5 mO
VPE height	30.00mm
VPE length	349.00mm
VPE width	135.00mm
Width	35.2mm
Width (inches)	1.3858 inch
Wire connection method	Clamping yoke connection
Wire cross-section, AWG, max.	AWG 12
Wire cross-section, AWG, min.	AWG 26
wire end ferrule	Stripping length
Wire/Cable Gauge	12AWG
