Weidmuller 1697960000 CBH Cable Mount 3.4mm Bundle 100 Pack Black

The Weidmüller CBH 27/27 SW is a black, self-adhesive cable mount designed to accommodate bundles up to 3.40 mm in diameter, with four threaded holes for secure attachment. Typically used in industrial settings, these mounts provide efficient cable management solutions. Each production packaging unit contains 100 pieces, facilitating large-scale applications.

Type	Cable Mount
Material	Polyamide 6.6
Colour	Black
Basic material	Plastic
Bundle Ø (max.)	3.40mm
Bundle Ø range	3.40 mm (max)
Depth	2mm
Depth (inches)	0.0787 inch
Diameter mounting hole	4.8
Diameter of fastening hole	4.8mm
ECLASS 14	23-15-25-22
ECLASS 15.0	23-15-25-22
ETIM 10	EC000449
ETIM 8.0	EC000449
ETIM 9.0	EC000449
For max. bundle diameter	4.8
For re-opening	No
GTIN (EAN)	4008190883034
Halogen	No
Height	27
Height (inches)	1.063 inch
Length	27mm
Length (inches)	0.0787 inch
Max. cable tie width	4mm
Min. tensile strength	80
Net weight	1.79g
Operating Temperature Range	-40...60°C
Operating temperature range, max.	60°C
Operating temperature range, min.	-40°C
Product information	Number of bags in box (pieces): 30
Qty.	3000 items
REACH SVHC	No SVHC above 0.1 wt%
ROHS	Conform
RoHS Compliance Status	Compliant without exemption
Suitable for cable tie width to	4.8
Tensile strength	80 N
Tensile strength (Pound-force)	18 lbf
UL 94 flammability rating	V-2
UV-resistant	Yes
Weight	1.6g
Width	27mm
Width (inches)	1.063 inch
Working temperature	-40 - 60
