Weidmüllers LED module 1507040000 features a 5-watt energy-efficient LED light. It is typically used in industrial or commercial settings where consistent, bright illumination is necessary. This module is robust and designed for integration into complex lighting systems.
| Type |
LED module |
| 60598-2-22 |
Type |
| Altitude |
= 3000 m |
| Amplitude of acceleration |
5 m/s² (@ 9-200 Hz) |
| Amplitude of deflection |
1.5 mm (2-9 Hz) |
| Certificate no. (cULus) |
E345151 |
| Connector cross-section, max. |
2.5mm² |
| Connector cross-section, min. |
0.5mm² |
| DC input voltage range |
20...60 V DC |
| Depth |
208mm |
| Depth (inches) |
8.189 inch |
| ECLASS 14 |
27-11-06-35 |
| ECLASS 15.0 |
27-11-06-35 |
| Efficiency class (according to EU |
Not required |
| ETIM 10 |
EC000996 |
| ETIM 8.0 |
EC000996 |
| ETIM 9.0 |
EC000996 |
| GTIN (EAN) |
4050118315547 |
| Halogen |
yes (PVC cable) |
| Height |
55mm |
| Height (inches) |
2.1654 inch |
| Humidity |
92 % @ 25°C |
| Insulation Voltage |
<500 V (housing/PE) |
| LED operating life |
> 50.000 h |
| Length |
208mm |
| Length (inches) |
8.189 inch |
| Light colour (CCT) |
Cool White, 6000K, |
| Light current |
454 lm |
| Line type |
Heluwind WK 103w- |
| Luminosity |
3000 cd |
| Mounting position, installation notice |
Arbitrary |
| Net weight |
602g |
| Nominal Current |
0.2 A |
| Nominal Voltage |
24 V |
| Operating Temperature |
-40 °C...55°C |
| Peak acceleration, type L |
70 m/s² |
| Pollution severity |
2 |
| Power Rating |
5 W |
| Pre-assembled connector cross-section 2.5 mm² |
Short-circuit protection |
| Protection Class |
II |
| Protection degree |
IP54 |
| REACH SVHC |
Lead 7439-92-1 |
| ROHS |
Conform |
| RoHS Compliance Status |
Compliant with exemption |
| SCIP |
bd6db3a5-1a47-48d8-a5e3-fdd82ef75173 |
| Shape of the LED module |
Other |
| Shock resistance EN 60721-3-3 |
Class 3M3 portable |
| Silicone |
No |
| Storage temperature |
-40 °C...85°C |
| Surge voltage category |
II |
| Type of connection |
Open cable end/length 2 |
| Type of mounting |
Screw mounting |
| UL 94 flammability rating |
V-0 |
| UL File Number Search |
UL Website |
| Vibration resistance EN 60721-3-3 |
Class 3M3 sinusoidal, |
| Width |
104mm |
| Width (inches) |
4.0945 inch |
