Wachendorff HD67562 Gateway Profibus/RS232/RS485 24V DC DIN Rail

The Wachendorff HD67562 is a gateway device that converts signals between Profibus, RS-232, and RS-485 interfaces, operating at 24 V DC. It serves as a slave in Profibus DP networks, facilitating seamless communication between different industrial protocols. Typical applications include automation and remote maintenance systems, enhancing connectivity within industrial environments.

Current Consumption	200mA
Depth	120mm
Dim	(W x H x D) 23 x 107 x 120 mm
Height	107mm
Interfaces	Profibus DP / RS232C / RS485
Maximum Operating Temperature	+70°C
Minimum Operating Temperature	-20°C
Misc Attribute 1	Slave / Profibus DP
Operating Temperature	-20 up to +70°C
Type	Gateway
Width	23mm
