W & P Products 154-020-1-50-00 Socket Connector 1x20 Pins 3A

Image Representative of Range

W & P Products 154-020-1-50-00 Socket Connector 1x20 Pins 3A

W & P Products
Order Code:

10-9566

Brand: W & P Products MPN: 154-020-1-50-00 EAN-13: 2050001143396
Qty Unit Price (Ex VAT)
2+ £2.32
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
118 in stock, despatched in 4 working days

The W & P Products 154-020-1-50-00 is a precision SIL socket connector with 1 x 20 pins. It supports a nominal current of 3 A, ensuring reliable performance in electronic applications. This connector is typically used in circuit boards and other electronic devices requiring precise interconnections.
Case Material Thermoplastic material
Connection Print
Connector orientation Parallel (to the PCB)
Connector Type Power strip, right angle
Contact Material Copper alloy
Contact surface Tin plated
CS 2.54mm
Dim (L x W x H) 50.8 x 8.30 x 5.84 mm
Factory colour Black
Height 5.84mm
Industrial packaging No
Insulation Resistance
> 1010Ω
Length 50.8mm
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute 2 Angled
Nominal Current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal Voltage 150V DC
Number of Rows 1
Pin length (PCB) 3.30mm
Pin length (receptacle) 2.40mm
Pin Ø 0.60mm
Pin shape Circular
Pins 1 x 20
Pins per row 20
Separable No
Socket depth 5.80mm
Temperature Range -55 - +125°C
Total number of pins 20
Type SIL socket (precision)
Width 8.30mm
