W & P 153-009-3-50-00 Socket Connector 3x3 3A Round/Square Pins

Image Representative of Range

W & P 153-009-3-50-00 Socket Connector 3x3 3A Round/Square Pins

W & P Products
Order Code:

10-9549

Brand: W & P Products MPN: 153-009-3-50-00 EAN-13: 2050001143303
Qty Unit Price (Ex VAT)
5+ £0.935
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
72 in stock, despatched in 4 working days

W & P Products manufactures the 153-009-3-50-00 precision socket connector. It features a 3 x 3 pin configuration and supports a nominal current of 3 A. Typically, it is used in applications requiring reliable and secure electrical connections.
Case Material Thermoplastic material
Connection Print
Connector orientation Perpendicular (to the PCB)
Connector Type Power strip, straight
Contact Material Copper alloy
Contact surface Tin plated
CS 2.54mm
Dim (L x W x H) 10.00 x 7.62 x 7.50 mm
Factory colour Black
Height 7.50mm
Industrial packaging No
Insulation Resistance
> 1010Ω
Length 10.00mm
Max. temperature +125°C
Min. temperature -55°C
Misc Attribute 2 Straight
Nominal Current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal Voltage 150V AC
Number of Rows 3
Pin length (PCB) 3mm
Pin length (receptacle) 2.40mm
Pin Ø 0.60mm
Pin shape Circular
Pins 3 x 3
Pins per row 3
Separable No
Socket depth 5.80mm
Temperature Range -55 - +125°C
Total number of pins 9
Type Receptacles (precision)
Width 7.62mm
