Vogt Connection Technology 3911 Blade Terminal 6.3x0.8mm Blue Part-Insulated

Image Representative of Range

Vogt Connection Technology 3911 Blade Terminal 6.3x0.8mm Blue Part-Insulated

Vogt Verbindungstechnik
Standard range
Order Code:

13-3971

Brand: Vogt Verbindungstechnik MPN: 3911 EAN-13: 2050000243646
Qty Unit Price (Ex VAT)
1+ £0.202
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1,686 in stock, despatched in 4 working days

The Vogt Verbindungstechnik blade terminal, model 3911, features a width of 6.3 mm and a thickness of 0.8 mm. It is partially insulated and coloured blue, designed for secure crimp connections. This connector is typically used in electrical applications where reliable and durable connections are required.
Connection angle 180°
Connector thickness 0.8mm
Connector width 6.3mm
Contact material Brass tin plated
Cross section 1.5 - 2.5mm²
Cross-section range 1.50 - 2.50 mm²
Factory colour Blue
Insulation PVC part-insulation
Insulation material PVC
Insulation type Partially insulated
Material (details) Brass, tin-plated
max. cross section 2.50mm²
Min. cross section 1.50mm²
Misc Attribute 1 6.3 x 0.8
Misc Attribute 2 connector
RoHS-compliant Yes
Size 6.3 x 0.8 mm
Support sleeve Yes
Type Blade terminal
