Vogt 3716P Parallel Connector 1.50-2.50 mm² Insulated Blue 1 piece

Image Representative of Range

Vogt 3716P Parallel Connector 1.50-2.50 mm² Insulated Blue 1 piece

Vogt Verbindungstechnik
Standard range
Order Code:

13-3816

Brand: Vogt Verbindungstechnik MPN: 3716P EAN-13: 2050000410215
Qty Unit Price (Ex VAT)
25+ £0.182
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
Available to back orderBack order, lead time 4 weeks

Vogt Verbindungstechnik manufactures the 3716P parallel connector, which is insulated and designed for wire sizes between 1.50 mm² and 2.50 mm². This blue crimp connector is typically used in electrical applications to join two wires in a parallel configuration. The connector facilitates secure and efficient electrical installations in various components and systems.
AWG (min.) 16
AWG max. 14
Contact material Cathode copper, tin plated
Cross section 1.5 - 2.0mm²
Cross-section range 1.50 - 2.50 mm²
Dim Ø D1 x Ø D2 x L x L1 x S 2,3 x 4,3 x 17 x 7 x 0,8 mm
Dimensions Ø D1 x Ø D2 x L x L1 x S 2,3 x 4,3 x 17 x 7 x 0,8 mm
Factory colour Blue
Inside diameter 2.3mm
Insulation material PA
Insulation type Insulated
Length 17mm
Material (details) E-Cu sn
max. cross section 2.50mm²
Min. cross section 1.50mm²
Outside Ø 4.3mm
RoHS-compliant Yes
Temperature range -10 - +75°C
Type Parallel connector
Wall thickness (details) 0.8mm
