TruConnect 211878 7.62mm 8 Way 15A 300V Header Straight Top Entry Closed

TruConnect
MPN
211878
Brand
TruConnect
EAN-13
5053556019823
Order Code
21-1878
Country of Origin
China
View Full Product Range (11)
Qty Unit Price (Ex VAT)
1+ £0.386
5+ £0.299
10+ £0.252
25+ £0.218
50+ £0.193
100+ £0.173
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Despatched same day - 500 in stockAdditional quantity lead time 5 months

Top entry, closed ended, header connector with 8 poles, 7.62mm pitch.
  • Vertical orientation
  • Closed ended
  • Rated voltage: 300V
  • Rated current: 15A
  • Moulded housing in green flame retardant PA66
  • PCB mounting, Solder
  • Pin header: tin plated brass
  • UL approved
Body Style Vertical Closed End Header
Pitch 7.62mm
No of Ways Per Row 8
No. of Rows 1
Current Rating 15A
Colour Green
Wire Gauge (AWG) N/A
Wire Gauge (mm²) N/A
Flame Retardancy UL94-V0
Material PA66
Mounting Feature PCB
Mounting Type Pluggable
Orientation Vertical
Voltage Rating 300V
