TruComponents 781976 Pushbutton ,Panel Mount,Off/(On),SPST-NO,Solder

TruComponents
Order Code:

78-1976

Brand: TruComponents MPN: 781976 EAN-13: 4064161299587
Qty Unit Price (Ex VAT)
2+ £3.62
5+ £3.53
10+ £3.45
25+ £3.37
50+ £3.30
100+ £3.23
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
729 in stock, despatched in 4 working days

The TruComponents 78-1976 Red Pushbutton is a momentary, illuminated switch rated at 250V AC and 6A. Designed for Snap in mounting, with guide lug for front panel mounting. It features a DPST configuration with an Off/(On) function, making it suitable for various electronic devices.
Type Pushbutton
Bulb Type Glow lamp
Colour Green
Connection Type C CEE 7/16 plug 4.8 mm
Contact Type 1 maker
Forward voltage U(F) 3V
Functions momentary
Lighting type Area illumination
Material Polyamide
Misc Attribute TC-R13-527AL-02GN
Recess diameter 20.2mm
Switch position 1 x Off/(On)
Switch/button features Protruding
Switching current (max.) 6A
Switching Voltage 250V AC
