TruComponents 745151 Blade Receptacle 6.4 mm 0.8 mm 180° Red 100 pieces

Image Representative of Range

TruComponents 745151 Blade Receptacle 6.4 mm 0.8 mm 180° Red 100 pieces

TruComponents
Standard range
Order Code:

13-2916

Brand: TruComponents MPN: 745151 EAN-13: 4016139206295
Qty Unit Price (Ex VAT)
1+ £5.62
10+ £5.22
50+ £5.09
100+ £4.96
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
337 in stock, despatched in 4 working days

TruComponents manufactures the 745151 blade receptacle, featuring a connector width of 6.4 mm and a thickness of 0.8 mm. This partially insulated, red crimp connector is ideal for secure electrical connections. It is commonly used in automotive and industrial wiring applications.
AWG (min.) 16
AWG max. 22
Connection angle 180°
Connector thickness 0.8mm
Connector width 6.4mm
Contact material Brass
Cross-section range 0.50 - 1.50 mm²
Factory colour Red
Insulation material PVC
Insulation type Partially insulated
Manufacturer part # 745151
max. cross section 1.50mm²
Min. cross section 0.50mm²
Misc Attribute FDD1.25-250
Size 6.4 x 0.8 mm
Support sleeve No
Temperature range Up to +70°C
Type Blade receptacle
