TruComponents 191579 Pin connector no ejector Pitch:1.27mm,pins: 10 2 Rows

TRUCOMPONENTS 191579 Pin Connector, featuring a compact 1.27mm pitch and 10 pins across 2 rows. Designed for seamless integration in various electronic applications, this connector ensures secure and stable connections even in demanding environments.

Type	Pin Connector
Number of Positions	10
Pitch	1.27mm
Number of Rows	2
Case Material	PBT
Colour	Black
Connection	Cut & Clip
Connector orientation	Perpendicular (to the PCB)
Connector Type	Pin strip, straight
Contact Material	Phosphor bronze
Cross Section	1.27mm
Dimensions	(L x W x H) 13.95 x 8.10 x 7.10 mm
Height	7.10mm
Industrial packaging	No
Length	13.95mm
Maximum Temperature	+105°C
Min. temperature	-40°C
Misc Attribute	F07a-10 BS1-G
Nominal Current	1A
Pins per row	5
Width	8.10mm
