TRU COMPONENTS 1581908 Zener diode DO-35 22V 522mW Zener voltage

TRU COMPONENTS 1581908, also known as ZPD-22-V, is a robust Zener diode designed for applications requiring voltage regulation and stabilisation. Encased in a DO-35 housing, this diode operates at a Zener voltage of 22 volts and can handle a maximum power dissipation of 522 milliwatts. Its primary function is to maintain a consistent voltage level, making it an effective component in circuits demanding reliable voltage reference or clamping features. Due to its precise voltage regulating capabilities, it is commonly employed in power supply circuits, signal processing, and as a voltage protection mechanism in electronic systems. Suitable for engineers seeking dependable performance, this diode ensures stability and efficiency across diverse electrical applications.

Type	Zener diode
Voltage	22V
Current	522mW
Package Style	DO 35
Configuration	1 diode
Impedance	25Ω
Impedance reference	5mA
Maximum Operating Temperature	+175°C
Mounting Type	Through-hole mounting
Operating temperature (min.)	-50°C
Residual reverse leakage current	24mA
U<sub>z</sub> (max.)	23.3V
U<sub>z</sub>(min.)	20.8V
