TracoPower TXLN 150-124 PSU Module 24V DC 6.3A 150W Enclosure 1 Pc

TracoPower
Order Code:

07-8446

Brand: TracoPower MPN: TXLN 150-124
Qty Unit Price (Ex VAT)
1+ £62.28
5+ £60.41
10+ £58.55
25+ £56.06
50+ £53.57
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

TracoPower's TXLN 150-124 AC/DC PSU module features a 24 V DC output at 6.3 A for a reliable 150 W power supply solution. This module is designed with solder lugs for PCB mounting, making it ideal for printed circuit board power supply applications. Typically, it's used in industrial machinery and automation systems requiring stable and efficient power conversion.
Connection Screw terminal
Dim (L x W x H) 198.15 x 99.0 x 30.0 mm
Height 30.0mm
Input voltage (max.) 264V AC
Length 198.15mm
Max. operating temperature (derating) 50°C
Max. output current 6.3A
Min. input voltage 85V AC
Misc Attribute 2 closed
MTBF 162800h
Number of Outputs 1
Operating temperature (max.) 70°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 6.3A
Output current (min.) 0mA
Output voltage (max.) 24V DC
Output voltage (min.) 24V DC
PFC Yes
Power 150W
Type AC/DC PSU module (+ enclosure)
Width 99.0mm
