TracoPower TEN Series 10W DC-DC Converters - Dual Output

TracoPower Brand: TracoPower

The TracoPower 10W DC-DC Converters are high performance converters in a compact 2" x 1" low profile package with industry standard footprint.

A high efficiency allows a wide operating temperature range of –40°C to +85°C, while a built-in EMI filter meets EN 55022, class A without any external components. Further standard features include over voltage protection and short-circuit protection.

Typical applications for these converters are battery operated equipment, instrumentation, distributed power architectures in communication and industrial electronics, everywhere where isolated, tightly regulated voltages are required.

  • Protected against permanent short circuit
  • Dimensions 50.8 x 25.4 x 10.2mm (L x W x H)
  • 3 year guarantee
Description Image Product Buy Pricing (Ex VAT) Supply Voltage Range Power Rating Mounting Style Number of Outputs Output Current Max Output Current Min Output Voltage Max Output Voltage Min Temperature Range
TracoPower TEN 10-1223 Dual Output DC DC Converter 10W
TracoPower TEN 10-1223 Dual Output DC DC Converter 10W
Extended range
Order code: 51-6799
MPN: TEN 10-1223

Available to back orderBack-order availability date - 31/12/2025
1+ £44.24
5+ £41.90
Price per unit Ex VAT 		9 to 18V 10W SMD 2 330mA -330mA 15V -15V -40 to +85°C
TracoPower TEN 10-2423 Dual Output DC DC Converter 10W
TracoPower TEN 10-2423 Dual Output DC DC Converter 10W
Extended range
Order code: 51-6807
MPN: TEN 10-2423

Available to back orderBack-order availability date - 31/12/2025
1+ £44.96
Price per unit Ex VAT 		18 to 36V 10W SMD 2 330mA -330mA 15V -15V -40 to +85°C
Order codeMftrs part no.Input voltageOutput voltageOutput current (max.)Efficiency
51-6797TEN 10-12219-18V DC±5V DC±1A78%
51-6798TEN 10-12229-18V DC±12V DC±415mA81%
51-6799TEN 10-12239-18V DC±15V DC±330mA80%
51-6805TEN 10-242118-36V DC±5V DC±1A80%
51-6806TEN 10-242218-36V DC±12V DC±415mA82%
51-6807TEN 10-242318-36V DC±15V DC±330mA82%
