Tianbo HJR4102E-L-5VDC-S-Z Relay PCB 5V DC 5A 1 Change-Over

Tianbo Electronics
Order Code:

10-8123

Brand: Tianbo Electronics MPN: HJR4102E-L-5VDC-S-Z EAN-13: 2050001760685
Qty Unit Price (Ex VAT)
10+ £0.577
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
275 available to back orderBack-order availability date - 09/01/2026

Tianbo Electronics manufactures the HJR4102E-L-5VDC-S-Z PCB relay, which operates at 5 V DC and supports a 5 A current with a single change-over contact. This miniature relay is designed for printed circuit boards and is ideal for applications requiring reliable switching, such as in consumer electronics or automotive systems. Its compact size makes it suitable for space-constrained environments.
Type PCB relay
Coil Voltage 5V DC
Switching Current 5A
Length 15.7mm
Width 10.4mm
Height 11.7mm
Connection Solder pins
Contact Material AgNi+Au
Contact Type 1 change-over
Control Mode monostable, 1 coil
Dim (L x W x H) 15.7 x 10.4 x 11.7 mm
Max. pick-up voltage 6.5V DC
Max. temperature +85°C
Min. pick-up voltage 3.8V DC
Min. temperature -30°C
Resistance (coil) 125Ω
