Tianbo Electronics HJR1-2C-L-05VDC PCB Relay 5V 2A 2 Change-Overs

Tianbo Electronics
Order Code:

10-8115

Brand: Tianbo Electronics MPN: HJR1-2C-L-05VDC EAN-13: 2050001760715
Qty Unit Price (Ex VAT)
10+ £0.795
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
674 in stock, despatched in 4 working days

The Tianbo Electronics HJR1-2C-L-05VDC is a PCB relay capable of handling 5 V DC and 2 A current with 2 change-over contacts. It is designed for printed circuit board applications and offers reliable switching functionality. Common uses include electronic devices and automated control systems.
Coil Voltage 5V DC
Contact Configuration 2CO (DPDT)
Switching Current 2A
Coil Resistance 125Ω
Connection Solder pins
Contact Material AgNi+Au
Control Mode monostable, 1 coil
Dimensions (L x W x H) 20.5 x 10 x 11.8 mm
Height 11.8mm
Length 20.5mm
Max. pick-up Voltage 8.5V DC
Max. temperature +85°C
Min. pick-up Voltage 3.8V DC
Minimum Temperature -30°C
Mounting Type PCB
Type PCB relay
Width 10mm
