Texas Instruments SN74LS07D Logic IC Gate and inverter Tube Logic ICs Gates

Texas Instruments SN74LS07D is a robust logic IC gate designed to meet the rigorous demands of modern electronic applications. As in the field of logic ICs, the SN74LS07D features open-collector outputs, enabling it to interface easily with systems requiring voltage levels different from the device's own power supply. This IC offers greater flexibility in design with its capability to drive higher voltage loads, supporting voltages up to 30V with a low-level output current of up to 40 mA. Its typical applications include use in buffering, driving LED displays, and level shifting in interface systems. With its versatility and reliable performance, the SN74LS07D serves as an essential component for engineers looking to implement efficient and effective logic solutions in their designs.

Logic IC Base Number	SN74LS07
Mounting Type	PCB mount
Operating temperature (max.)	70°C
Operating temperature (min.)	0°C
Type	Logic IC - Gate and inverter
