Texas Instruments CD74HC4094PWR Logic IC Shift register Tape Full reel

Texas Instruments CD74HC4094PWR is a high-performance shift register integrated circuit that implements a buffered HCMOS logic and is designed for high-speed memory and data register applications. This eight-stage shift-and-store circuit is characterised by its high output drive capability and low dynamic power consumption, making it highly suitable for interfacing with both digital and analogue systems. Utilising advanced high-speed CMOS technology, the device operates effectively within a supply voltage range of 2V to 6V, ensuring versatile integration into various systems. Common engineering applications for the CD74HC4094PWR include data buffering, display interfaces, and serial-to-parallel data conversion in microprocessor and microcontroller systems. The part is typically packaged in full reels, facilitating automated assembly processes.

Mounting Type	PCB mount
Operating temperature (max.)	125°C
Operating temperature (min.)	-55°C
Product Type	Logic IC - Shift register
Series	CD74HC4094
Type	CD74HC4094PWR
