Telegartner 100024840 SMB Connector Plug Vertical Mount 50 Ω Snap-on 1 piece

Image Representative of Range

Telegartner 100024840 SMB Connector Plug Vertical Mount 50 Ω Snap-on 1 piece

Telegartner
Order Code:

13-1179

Brand: Telegartner MPN: 100024840 EAN-13: 4018359122522
Qty Unit Price (Ex VAT)
1+ £5.29
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
19 available to back orderBack-order availability date - 11/01/2026

Telegärtner's SMB connector, model 100024840, is a plug designed for vertical mounting with a 50 O impedance. It is typically used in high-frequency RF equipment and coaxial applications. This connector is ideal for antenna connections and other communications devices requiring reliable signal transmission.
Type SMB connector
Impedance 50Ω
Contact Termination Screws
Cable category RG 316/U
Cable Ø 2.60mm
Case Material Brass gold plated
Connector Type Plug, vertical mount
Contact Material Brass gold plated
Insulation Material PTFE
Insulation Resistance ≥ 1 GΩ
Max. frequency 4GHz
Mounting Hole Diameter 4.9mm
Seal type Push-Pull
Temperature Range -55 - 155°C
