TE Connectivity 928814-1 is a female unshrouded terminal designed for reliable electrical connections.
It features a 6.3 mm tab size, ensuring compatibility with a range of connector systems.
The terminal is suitable for applications requiring secure, high-performance connections in automotive and industrial settings.
It provides ease of installation and maintenance.
| Insulation |
Non-Insulated |
| Colour |
Metal |
| Tab Width |
0.25inch |
| Tab Thickness |
0.032inch |
| Gender |
Male |
| Body Material |
Brass |
| Body Plating |
Tin |
| Contact Material |
Copper, Brass |
| Contact Mating Area Plating Material Thickness |
118.11 – 314.96 |
| Contact Plating |
Tin |
| Contact Underplating Material Thickness |
31.49 – 196.85 |
| Depth |
7.6mm |
| Insulation Option |
Uninsulated |
| Length |
16mm |
| Material |
Copper |
| Mating Tab Thickness |
.032 |
| Mating Tab Width |
.25 |
| Misc Attribute |
TE AMP FASTON Terminals - Premier & Commercial |
| Mount |
Through Hole |
| Operating Temperature Range |
-67 – 221 |
| Orientation |
Right Angle |
| Package Quantity |
10000 |
| Packaging |
Box |
| Packaging Method |
Box |
| Packaging Quantity |
10000 |
| Packaging Type |
Bag |
| PCB Contact Termination Area Plating Material Thickness |
118.11 – 314.96 |
| PCB Thickness (Recommended) |
.062 – .098 |
| Plating |
Tin |
| Product Terminates To |
Printed Circuit Board |
| Radiation Hardening |
No |
| Reach SVHC Compliant |
No |
| RoHS Compliant |
Yes |
| Series |
Faston™ |
| Tab Length |
0.358inch |
| Terminal Material |
Brass |
| Terminal Orientation |
Right Angle |
| Terminal Plating Material |
Tin |
| Termination |
Solder |
| Termination Method to PCB |
Through Hole - Screw |
| Type |
PCB Terminals |
