TE Connectivity 776531-1 AMPSEAL16 Socket Housing 6 Pins

MPN: 776531-1
Brand: TE Connectivity
EAN-13: 2050002890732
Order Code: 07-4933
Country of Origin: Italy

RoHS Compliant
Free UK shipping available

View Full Product Range (10)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£4.02
10+	£3.64
100+	£3.37

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Despatched within 4 working days - 62 in stock

Product Details
Product Range
Data Sheets
Quick Quote

TE Connectivity's 776531-1 is a plug assembly featuring six positions.

It is red and designed for 20-18 AWG wires, making it suitable for medium gauge connections.

The plug is shrouded and female, ensuring secure and protected connections.

Typically, it is used in electronics and electrical applications requiring reliable connectivity.

Type	Socket, straight
Number of Contacts	6
Gender	Female
Number of Rows	2
Body Material	PBT
Case Material	Thermoplastic material
Code	A
Colour	Red
Connector contact surface	Tin plated
Connector System	automotive
Contact Type	Female Socket
Current Rating	13A
Depth	39.85mm
Dimensions	(L x W x H) 25.33 x 36.6 x 31 mm
Flammability Rating	UL94 HB
Height	31mm
Housing Color	Red
Hybrid Connector	No
Industrial packaging	No
Insulation Material	Thermoplastic material
IP Rating	IP6K9K
Length	25.33mm
Material	Thermoplastic
Max Operating Temperature	125°C
Max. temperature	+125°C
Min Operating Temperature	-40°C
Min. temperature	-40°C
Misc Attribute	AMPSEAL16
Mount	Free Hanging, Cable
Nominal Voltage	250V DC
Orientation	Straight
Package Quantity	22
Packaging	Bulk
Pin shape	Circular
Pins per row	3
Pitch	0.177inch
Polarized	Yes
Radiation Hardening	No
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Row Spacing	5.3mm
Sealable	Yes (With)
Series	AMPSEAL16
Serviceable	Yes
Strain Relief	Add By Accessory
Termination	Crimp
Width	36.6mm
