The TE Connectivity 66261-2 bullet connector is a single contact pin designed for the CPC series of round connectors. It features a robust design suitable for various electrical applications, offering reliable connectivity in automotive, industrial, and telecommunications sectors. This connector does not have specific voltage or current ratings as it is just the contact pin used as part of a connector assembly.
| Type |
Pin |
| Number of Contacts |
1 |
| Gender |
Male |
| Number of Rows |
N/A |
| Circuit Application |
Power |
| Compatible Insulation Diameter Range |
.135 – .16 |
| Connection |
Crimp |
| Connection Angle |
180° |
| Contact Base Material |
Copper |
| Contact Current Rating |
35a |
| Contact Current Rating (Max) |
35 |
| Contact Gender |
Male |
| Contact Material |
Copper |
| Contact Mating Area Plating Material |
Gold (Au) |
| Contact Mating Area Plating Material Thickness |
30 |
| Contact Plating |
Gold |
| Contact Type |
Tab |
| Contact Underplating Material |
Copper |
| Current Rating |
35A |
| Depth |
5.58mm |
| ELV |
Compliant |
| Height |
6.09mm |
| Insulation Diameter |
4.06mm |
| Length |
31.62mm |
| Mating Tab Thickness |
.105 |
| Mating Tab Width |
.23 |
| Maximum Temperature |
+85°C |
| Min. temperature |
-25°C |
| Misc Attribute |
CPC Baureihe 3 |
| Mount |
Cable |
| Nominal Voltage |
150V AC |
| Operating Temperature Range |
-40 – 185 |
| Orientation |
Straight |
| Package Quantity |
100 |
| Packaging |
Bag |
| Packaging Method |
Bag |
| Packaging Quantity |
100 |
| Product Terminates To |
Wire & Cable |
| Radiation Hardening |
No |
| Reach SVHC Compliant |
No |
| RoHS Compliant |
Yes |
| Series |
CPC |
| Shielding |
Unshielded |
| Termination |
Crimp |
| Termination Method to Wire & Cable |
Crimp |
| Wire Gauge (AWG) |
16AWG |
| Wire Gauge (Max) |
16AWG |
| Wire Gauge (Min) |
12AWG |
| Wire Insulation Support |
With |
| Wire Size |
16 |
| Wire/Cable Type |
Discrete |
