TE Connectivity 640919-1 is a PIDG terminal designed for wires sized 16-14 AWG.
The terminal features a female unshrouded connector in a striking blue colour.
It ensures secure and reliable electrical connections and is commonly used in automotive and industrial applications.
This component is valued for its durability and ease of installation.
| Insulation |
PA 6.6 |
| Colour |
Blue |
| Gender |
Female |
| Barrel Type |
Closed |
| Body Material |
Brass |
| Body Plating |
Tin |
| Color |
Blue |
| Compatible Insulation Diameter Range |
.17 |
| Compatible With Agency/Standards Products |
RU (UL Component Program) |
| Connection Angle |
180° |
| Connector thickness |
0.5mm |
| Connector Width |
4.8mm |
| Contact Base Material |
Brass |
| Contact Material |
Brass tin plated |
| Contact Plating |
Tin |
| Crimp Type |
Compression Crimp |
| Cross-section range |
1.04 - 2.602 mm² |
| Depth |
5.84mm |
| Insulated Wire Support |
Yes |
| Insulation Diameter |
4.32mm |
| Insulation Material |
Nylon |
| Insulation Option |
Partially Insulated |
| Insulation Type |
Partially insulated |
| Length |
20.356mm |
| Mating Retention Type |
Dimple |
| Mating Tab Thickness |
.02 |
| Mating Tab Width |
.187 |
| max. cross section |
2.602mm² |
| Maximum Wire Size AWG |
14 |
| Min. cross section |
1.04mm² |
| Misc Attribute |
PIDG-FASTON |
| Mount |
Free Hanging |
| Orientation |
Straight |
| Package Quantity |
1000 |
| Packaging |
Loose Piece |
| Packaging Method |
Loose Piece |
| Packaging Quantity |
1000 |
| Plating |
Tin |
| Product Length |
.8 |
| Product Terminates To |
Wire & Cable |
| Radiation Hardening |
No |
| Reach SVHC Compliant |
Unknown |
| RoHS Compliant |
Yes |
| Series |
Faston, PIDG |
| Size |
4.8 x 0.5 mm |
| Support sleeve |
Yes |
| Temperature Range |
105°C |
| Terminal Material |
Brass |
| Terminal Orientation |
Straight |
| Terminal Plating Material |
Tin |
| Termination |
Receptacle |
| Type |
Blade receptacle |
| Voltage Rating (AC) |
300v |
| Wire Gauge (Max) |
14AWG |
| Wire Gauge (Min) |
16AWG |
| Wire Insulation Support |
With |
| Wire Size |
2050 – 5180 |
| Wire/Cable Gauge |
16AWG |
