The TE Connectivity 61316-1 faston Terminal is a female unshrouded terminal designed for secure electrical connections.
It features a 0.250-inch tab and accommodates wire sizes from 22 to 18 AWG.
Made for ease of use, it provides reliable performance in automotive and industrial applications.
This terminal is commonly used for various wiring tasks where quick disconnection is required.
| Insulation |
Non-Insulated |
| Colour |
Metal |
| Tab Width |
0.25inch |
| Tab Thickness |
0.032inch |
| Gender |
Male |
| Barrel Type |
Open |
| Body Material |
Brass |
| Body Plating |
Tin |
| Compatible Insulation Diameter Range |
.084 – .125 |
| Contact Base Material |
Brass |
| Contact Plating |
Tin |
| Crimp Type |
F-Crimp |
| Current Rating |
28a |
| Depth |
6.5mm |
| ELV |
Compliant |
| Insulated Wire Support |
Yes |
| Insulation Diameter |
0.125inch |
| Insulation Option |
Uninsulated |
| Lead Free |
Not Applicable |
| Length |
1.141inch |
| Material |
Brass |
| Mating Retention Type |
Locking Lance |
| Mating Tab Thickness |
.032 |
| Mating Tab Width |
.25 |
| Maximum Operating Temperature |
105°C |
| Minimum Operating Temperature |
-30°C |
| Misc Attribute |
TE AMP FASTIN-FASTON |
| Mount |
Free Hanging |
| Operating Temperature Range |
-40 – 230 |
| Orientation |
Straight |
| Package Quantity |
1000 |
| Packaging |
Loose Piece |
| Packaging Method |
Loose Piece/Carton |
| Packaging Quantity |
1000 |
| Packaging Type |
Bag |
| Plating |
Tin |
| Product Length |
1.141 |
| Product Terminates To |
Wire & Cable |
| Radiation Hardening |
No |
| Reach SVHC Compliant |
Unknown |
| RoHS Compliant |
Yes |
| Series |
Fastin-Faston |
| Tab Length |
0.62inch |
| Terminal Material |
Brass |
| Terminal Orientation |
Straight |
| Terminal Plating Material |
Tin |
| Termination |
Tab |
| Test Voltage |
1kV |
| Type |
Quick Disconnects |
| Wire Gauge (Max) |
18AWG |
| Wire Gauge (Min) |
22AWG |
| Wire Insulation Support |
With |
| Wire Size |
22 – 18 |
| Wire/Cable Diameter |
3.18mm |
| Wire/Cable Gauge |
22AWG |
