The TE Connectivity 33462 is a shoe unit used in precision tooling applications.
Designed for durability, it ensures accurate punching and shaping processes.
It is typically employed in manufacturing settings requiring high precision and repeatability.
This component is essential for achieving consistent results in tool and die operations.
- Hole diameter: 8.3 mm
- Cross-section: 6.70 - 10.5mm²
| Colour |
Metal |
| Insulated |
Uninsulated |
| Stud Size |
8mm |
| Barrel Type |
Closed |
| Body Material |
Copper |
| Body Plating |
Tin |
| Color |
Red |
| Contact Material |
Copper, Silver |
| Contact Plating |
Tin |
| Cross-section |
6.70 - 10.5mm2 |
| Depth |
15.09mm |
| Finish |
Tin |
| Gender |
Female |
| Government Qualified |
No |
| Heavy Duty |
No |
| Inside Diameter |
4.37mm |
| Insulated Wire Support |
No |
| Insulation |
Non-Insulated |
| Lead Free |
Lead Free |
| Length |
1.168inch |
| Material |
Copper, Tin |
| Max Operating Temperature |
170°C |
| Maximimum Wire Gauge (AWG) |
8 |
| Mount |
Free Hanging |
| Mounting Type |
Wire Mount |
| Number of Holes |
1 |
| Operating Temperature Range |
0 – 338 |
| Orientation |
Straight |
| Outer Width |
15.1mm |
| Overall Length |
22.1mm |
| Package Quantity |
100 |
| Package/Case |
Metal |
| Packaging |
Loose Piece |
| Packaging Method |
Loose Piece |
| Packaging Quantity |
100 |
| Plating |
Tin |
| Product Length |
1.168 |
| Product Type |
Ring Terminal |
| Radiation Hardening |
No |
| Reach SVHC Compliant |
No |
| RoHS Compliant |
Yes |
| Sealable |
No |
| Series |
Solistrand |
| Stud Diameter |
0.328inch |
| Terminal Orientation |
Straight |
| Terminal Plating Material |
Tin |
| Terminal Type |
Ring Terminal Connector |
| Termination |
Crimp |
| Thickness |
1.2mm |
| Tongue Thickness |
1.19mm |
| Wire Insulation Support |
Without |
| Wire/Cable Diameter |
4.2mm |
| Wire/Cable Gauge |
8AWG |
