TE Connectivity 32053 PIDG Terminal Unshrouded Female 22-16AWG 22-18MIL

MPN: 32053
Brand: TE Connectivity
Order Code: 13-8585
Country of Origin: USA

RoHS Compliant
Free UK shipping available

Inc VAT

Qty	Unit Price (Ex VAT)
1000+	£0.539

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 1000

Available to back orderBack order, lead time 4 months

Product Details
Quick Quote

The TE Connectivity 32053 PIDG Terminal is an unshrouded female connector.

It supports wire sizes from 22-16 AWG and insulation thickness of 22-18 mil.

Designed for reliable and easy termination, it features durable construction for secure connections.

Typical applications include automotive, industrial, and commercial electrical systems.

Insulation	Insulated
Colour	Red
Tab Thickness	0.84mm
Gender	Female
Barrel Type	Closed
Body Material	Copper
Body Plating	Tin
Compatible Insulation Diameter Range	.105 – .14
Contact Material	Copper, Silver
Contact Plating	Tin
Depth	9.52mm
ELV	Compliant
Government Qualified	No
Heavy Duty	No
Insulated Wire Support	Yes
Insulation Diameter	0.14inch
Insulation Material	Nylon
Insulation Option	Partially Insulated
Length	23.06mm
Material	Copper
Mount	Free Hanging
Operating Temperature Range	0 – 221
Orientation	Straight
Package Quantity	1000
Packaging	Loose Piece
Packaging Method	Loose Piece
Packaging Quantity	1000
Plating	Tin
Product Length	.908
Product Weight	1.029
Radiation Hardening	No
RoHS Compliant	Yes
Sealable	No
Series	PIDG
Shrouded	No (Without)
Stud Diameter	4.34mm
Stud Size	M4
Terminal Orientation	Straight
Terminal Plating Material	Tin
Termination	Crimp
Tongue Thickness	0.79mm
Type	Spade Terminals
Voltage Rating	300v
Width	9.53mm
Wire Gauge (Max)	22AWG
Wire Gauge (Min)	16AWG
Wire Insulation Support	With
Wire Size	509 – 3260
