TE Connectivity 3-1462039-0 IM23TS Industrial Relay 5V DC 2 Change-Overs

The TE Connectivity IM23TS industrial relay is designed for use in 5 V DC applications and features two change-over contacts. This relay is ideal for switching tasks in industrial automation systems where reliable performance is essential. Its robust construction ensures long-lasting operation in demanding environments.

Coil Voltage	5V DC
Contact Configuration	2CO (DPDT)
Actuating System	DC
Coil Current	10mA
Coil Power	50mW
Coil Resistance	500Ω
Coil Type	Non-Latching
Coil Voltage (DC)	5v
Connection	THT
Contact Current Rating	2a
Contact Material	Gold (Au)
Contact Plating	Gold
Contact Voltage Rating (DC)	220v
Current Rating	2a
Depth	6mm
Dimensions	(L x W x H) 10 x 6 x 5.65 mm
ELV	Compliant
Height	5.65mm
Insertion Loss	-0.03dB
Length	10mm
Max Current Rating	2a
Max Voltage Rating (AC)	250v
Max Voltage Rating (DC)	220v
Maximum Operating Temperature	85°C
Maximum Temperature	+85°C
Min Operating Temperature	-40°C
Min. temperature	-40°C
Minimum Operating Temperature	-40°C
Misc Attribute	IM23TS
Mount	Through Hole
Nominal Voltage	5V DC
Number of Contacts	2
Operate Time	1ms
Package/Case	DIP
Packaging	Rail/Tube
Relay Type	Relay
Release Time	3ms
RoHS Compliant	Yes
Series	IM, AXICOM
Termination	PCB
Throw Configuration	DPDT
Type	Industrial relay
Voltage Rating (AC)	250v
Weight	0.75g
Width	6mm
