TE Connectivity 2-34148-1 is a spade lug terminal designed for 22-16AWG wire.
It is unshrouded, allowing for easy and quick connections.
The terminal is ideal for use in electrical and electronic applications requiring reliable termination.
Commonly used in automotive and industrial equipment wiring tasks.
| Colour |
Red |
| Insulated |
Partially Insulated |
| Stud Size |
Not Specifiedmm |
| Maximum Wire Size (mm2) |
1.5mm² |
| Barrel Type |
Closed |
| Body Material |
Copper |
| Body Plating |
Tin |
| Color |
Red |
| Compatible Insulation Diameter Range |
.105 – .14 |
| Contact Material |
Copper, Copper Alloy |
| Contact Plating |
Tin |
| DC Rated Voltage |
600v |
| Depth |
7.92mm |
| Gender |
Female |
| Government Qualified |
No |
| Heavy Duty |
No |
| Insulated Wire Support |
Yes |
| Insulation |
Insulated |
| Insulation Color |
Red |
| Insulation Diameter |
0.14inch |
| Insulation Material |
Vinyl |
| Length |
21.74mm |
| Material |
Copper |
| Maximimum Wire Gauge (AWG) |
16 |
| Mount |
Free Hanging |
| Number of Holes |
1 |
| Operating Temperature Range |
0 – 221 |
| Orientation |
Straight |
| Package Quantity |
5000 |
| Packaging |
Tape and Reel |
| Packaging Method |
Tape Mounted |
| Packaging Quantity |
5000 |
| Plating |
Tin |
| Plating Thickness |
2.54um |
| Product Length |
.86 |
| Product Type |
Ring Terminal |
| Product Weight |
.813 |
| Radiation Hardening |
No |
| Reach SVHC Compliant |
No |
| RoHS Compliant |
Yes |
| Sealable |
No |
| Series |
Plasti-Grip |
| Shrouded |
No (Without) |
| Stud Diameter |
4.74mm |
| Terminal Gender |
Female |
| Terminal Orientation |
Straight |
| Terminal Plating Material |
Tin |
| Termination |
Crimp |
| Thickness |
0.79mm |
| Tongue Thickness |
0.79mm |
| Voltage Rating (AC) |
600v |
| Wire Gauge (Max) |
16AWG |
| Wire Gauge (Min) |
22AWG |
| Wire Insulation Support |
With |
| Wire/Cable Diameter |
3.56mm |
| Wire/Cable Gauge |
16AWG |
