TE Connectivity's 1888811-1 is a telecom connector with 38 female shrouded contacts.
It offers secure connections and is designed for reliable performance in telecommunications applications.
The connector's robust construction ensures durability in various environments.
It is typically used in network equipment and communication infrastructure.
| Type |
HDMI Connectors |
| Plug / Socket |
Receptacle |
| Mounting Type |
Board Mount |
| No. of Ways |
38 |
| Mounting Direction |
Right Angle |
| Plating Material |
Tin |
| Centerline (Pitch) |
0.9906mm |
| Circuit Application |
Signal |
| Colour |
Black |
| Connector & Contact Terminates To |
Printed Circuit Board |
| Connector Profile |
Standard |
| Connector System |
Cable-to-Board |
| Connector Type A |
HDMI |
| Contact Current Rating |
500mA |
| Contact Current Rating (Max) |
.5 |
| Contact Material |
Copper Alloy |
| Contact Mating Area Plating Material |
Gold Flash over Palladium Nickel |
| Contact Mating Area Plating Material Thickness |
11.81 |
| Contact Plating |
Gold |
| Depth |
28mm |
| ELV |
Compliant |
| Flammability Rating |
UL94 V-0 |
| Gender |
Receptacle |
| Housing Colour |
Black |
| Insulation Colour |
Black |
| Length |
18.9mm |
| Mating cycles |
10000 |
| Max Operating Temperature |
221°C |
| Min Operating Temperature |
-67°C |
| Mount |
Through Hole |
| Number of Contacts |
38 |
| Number of Ports |
2 |
| Number of Positions |
38 |
| Operating Temperature Range |
-67 – 221 |
| Orientation |
Right Angle |
| Package Quantity |
648 |
| Packaging |
Tray |
| Packaging Method |
Box & Tray |
| PCB Mount Retention Type |
Straight Leg |
| Pitch |
0.039inch |
| Plating |
Matte, Tin |
| Plating Thickness |
0.3um |
| Preloaded |
Yes |
| Radiation Hardening |
No |
| RoHS Compliant |
Yes |
| Shielding |
Shielded |
| Tail Length |
2.6mm |
| Termination |
Through Hole |
| Termination Method to PCB |
Through Hole - Solder |
| Termination Post & Tail Length |
.102 |
| Voltage Rating |
40v |
